HUSQVARNA K770 STANDARD 12"/14" Consaw (WITH FREE BLADE)

HIGHLIGHTS OF THE NEW HUSQVARNA K770

DIGITAL IGNITION WITH OPTIMISED TIMING

The digital ignition module is updated to provide a powerful spark with optimised timing, enabling easy start and efficient combustion.

A HEAVIER DUTY CUTTING ARM

The newly-designed cast magnesium crankcase has a three-bolt joint to attach the cutting head, enabling higher torsional rigidity than the previous two-bolt solution.

A SMARTER WAY TO KEEP THE DRIVE BELT TENSIONED

The spring-loaded, semi-automatic SmartTension™ system makes it easy to ensure that the drive belt is always kept in the correct tension. This allows for optimal power transmission as well as minimum wear and maximum life of the belt.

COOLER TRANSMISSION

The clutch cooling fan lowers the operating temperature inside the belt cover, extending the service life for the transmission components, including the drive belt.

Easy and optimal belt tensioning

The semi-automatic SmartTension minimises the risk of under- and over tensioning

Light and powerful

A light, compact and powerful machine with superior power-to-weight ratio.

Heavy-duty cutting arm

The new-designed cast magnesium crankcase has a three-bolt joint to attach the cutting head, enabling higher torsional rigidity than the previous two-bolt solution.

Long service intervals

A strong Poly-V belt combined with our maintenance-free starter DuraStarter™ and efficient filter-system Active Air Filtration™ ensures long service intervals.

• Digital ignition with optimised timing
• Exceptionally low vibrations
• Easy to start
• Maintenance-free air filter
• High power with less fuel
• Optimised engine performance
• Less slurry and low water consumption
• Easy to change blade guard position
• Fits multiple blade bushings
• Less emissions and fuel consumption
• Blade retarder
• Maintenance-free starter
• Reduced wear
• Cuts close to walls or ground
• Active Air Filtration™
• Anti-vibration system
• DuraStarter™
• Poly-V belt
• SmartCarb™
• Asphalt
• Blocks, curbstones and pavers
• Burying of cables
• Cast concrete
• Floors and walls
• Rails
• Rescue cutting
• Blade shaft and bearings

Digital ignition with optimised timing

Provides a powerful spark with optimized timing, enabling easy start and efficient combustion.

TECHNICAL SPECIFICATION

Displacement: 74 cm³

Engine power: 3.7 kW

Blade diameter: 300mm(12") /  350mm(14")

Dry weight excl blade: 9.9kg

Max. cutting depth: 100mm(12") /125 mm(14")

Vibrations: < 2.5 m/s²

(Does not include blade)
