Description
- Featuring an 81cm (32") fabricated deck constructed from 7-gauge steel
- Powered by a Kawasaki® FS 600 V-Twin 600cc engine
- Thumb release and vertical pin system with 15 cutting positions
- Range of optional accessories is available
- 5-year or 1000 hour warranty - no hour limit for first 2 years
Featuring all the benefits of a zero-turn mower but with the low-profile form of a large walk-behind mower and near perfect visibility of the cutting area. The ARROW stand-on can quickly mow larger lawns yet also cut intricate shaped grass dotted with trees, flower beds and other obstacles. Accelerate your commercial cutting workflow with the 'hop on, hop off' driving style of this stand-on zero-turn.
EASY ACCESS & MANOEUVRABILITY
Both the 81cm (32″) and 91cm (36″) decks enable entry to mowing areas with limited access and allow easier working in tight spaces.
FLIP-UP SUSPENSION PLATFORM
The raised flip-up suspension platform offers the user better visibility than a walk-behind. It also eases vibration, providing all-day standing comfort. The flip-up mechanism enables quick conversion from a stand-on to a walk-behind, for maximum versatility for the user.
ADJUSTABLE CRUISE BAR
Allows the operator to reduce and increase the unit’s maximum speed in tight working environments.
CONTROL PANEL
The ergonomic control panel allows the operator to easily adjust settings on the move.
HEIGHT-OF-CUT SYSTEM
Less deck-lifting force, a thumb release and vertical pin system add ease to cutting height adjustments.
PREMIUM ENGINE
A Kawasaki FS600 V-Twin premium engine is fitted for power, performance and fuel efficiency.
LOWERED CENTRE OF GRAVITY
Reshaped geometry and redistributed weight provide increased hillside stability and confidence in your ride.
- Model Arrow32”(994302)
- Engine Kawasaki FS600V 603cc
- Transmission Hydro-Gear ZT-3100
- Transaxle Fuel Capacity 22.7 liters
- Drive Speed Approx 12.8kph(FWD) 4.8(REV)
- Deck 7ga Fabricated
- Number of blades 2 Deck
- Lift System Manual
- Cutting Width 32”/81cm
- Cutting Height 7 Positions 1.5”-5”/3.8cm-12.7cm
- Seat N/A
- Hour Meter Yes
- ROPS No
- Warranty(Machine) 5 Year/1000 Hour
